GoMill Düz Ağızlı Karbid Frezlər (Kennametal ABŞ)
Ümumi məqsədli karbid frezlər
Polad, paslanmaz Polad və tökmə polad üçün nəzərdə tutulmuşdur
Məhsul xüsusiyyətləri
| Alət Kodu | Grade | Ağız Diametri | Gövdə Diametri | Kəsmə Boyu | Ümumi Boy | Radius/Haşiyə | Radius/Haşiyə Ölçüsü | Ağız Sayısı | Fiyat | Seç |
|---|---|---|---|---|---|---|---|---|---|---|
| 2CH0400DK005A | KC633M | 4 | 6 | 12.768 | 54 | H | 0.1 | 2 | 27.70 € |
|
| 2CH0400DL008A | KC633M | 4 | 6 | 15.768 | 57 | H | 0.1 | 2 | 27.70 € |
|
| 2CH0450DK005A | KC633M | 4.5 | 6 | 13.701 | 54 | H | 0.1 | 2 | € |
|
| 2CH0450DL008A | KC633M | 4.5 | 6 | 16.701 | 57 | H | 0.1 | 2 | 27.70 € |
|
| 2CH0500DK006A | KC633M | 5 | 6 | 14.134 | 54 | H | 0.1 | 2 | 27.70 € |
|
| 2CH0500DL010A | KC633M | 5 | 6 | 17.634 | 57 | H | 0.1 | 2 | 27.70 € |
|
| 2CH0600DK007A | KC633M | 6 | 6 | 7 | 54 | H | 0.1 | 2 | 27.70 € |
|
| 2CH0600DL010A | KC633M | 6 | 6 | 10 | 57 | H | 0.1 | 2 | 27.70 € |
|
| 2CH0700DK008A | KC633M | 7 | 8 | 18.634 | 58 | H | 0.1 | 2 | 33.05 € |
|
| 2CH0700DL013A | KC633M | 7 | 8 | 23.63 | 63 | H | 0.1 | 2 | 35.78 € |
|
| 2CH0800DK009A | KC633M | 8 | 8 | 9 | 58 | H | 0.2 | 2 | 33.05 € |
|
| 2CH0800DL016A | KC633M | 8 | 8 | 16 | 63 | H | 0.2 | 2 | 35.78 € |
|
| 2CH0900DK010A | KC633M | 9 | 10 | 22.634 | 66 | H | 0.2 | 2 | 48.84 € |
|
| 2CH0900DL016A | KC633M | 9 | 10 | 29.126 | 72 | H | 0.2 | 2 | 51.03 € |
|
| 2CH1000DK011A | KC633M | 10 | 10 | 11 | 66 | H | 0.2 | 2 | 48.84 € |
|
| 2CH1000DL019A | KC633M | 10 | 10 | 19 | 72 | H | 0.2 | 2 | 51.03 € |
|
| 2CH1200DK012A | KC633M | 12 | 12 | 12 | 73 | H | 0.3 | 2 | 59.19 € |
|
| 2CH1200DL022A | KC633M | 12 | 12 | 22 | 83 | H | 0.3 | 2 | 61.65 € |
|
| 2CH1400DK014A | KC633M | 14 | 14 | 14 | 75 | H | 0.3 | 2 | 66.90 € |
|
| 2CH1400DL022A | KC633M | 14 | 14 | 22 | 83 | H | 0.3 | 2 | 76.80 € |
|
| 2CH1600DK016A | KC633M | 16 | 16 | 16 | 82 | H | 0.3 | 2 | 82.62 € |
|
| 2CH1600DL026A | KC633M | 16 | 16 | 26 | 92 | H | 0.3 | 2 | 82.62 € |
|
| 2CH1800DK018A | KC633M | 18 | 18 | 18 | 84 | H | 0.3 | 2 | 82.62 € |
|
| 2CH1800DL026A | KC633M | 18 | 18 | 26 | 92 | H | 0.3 | 2 | 112.47 € |
|
| 2CH2000DK020A | KC633M | 20 | 20 | 20 | 92 | H | 0.3 | 2 | 122.66 € |
|
| 2CH2000DL032A | KC633M | 20 | 20 | 32 | 104 | H | 0.3 | 2 | 140.50 € |
|
| 2CH0400ML019A | KC633M | 4 | 4 | 19 | 63 | H | 0.1 | 2 | 25.04 € |
|
| 2CH0400MR012A | KC633M | 4 | 4 | 12 | 50 | H | 0.1 | 2 | 25.04 € |
|
| 2CH0400MX031A | KC633M | 4 | 4 | 31 | 75 | H | 0.1 | 2 | 28.28 € |
|
| 2CH0450MR014A | KC633M | 4.5 | 6 | 21.4 | 50 | H | 0.1 | 2 | 26.75 € |
|
| 2CH0500ML020A | KC633M | 5 | 5 | 20 | 63 | H | 0.1 | 2 | 27.84 € |
|
| 2CH0500MR014A | KC633M | 5 | 5 | 14 | 50 | H | 0.1 | 2 | 24.89 € |
|
| 2CH0500MX031A | KC633M | 5 | 5 | 31 | 100 | H | 0.1 | 2 | 31.48 € |
|
| 2CH0550MR014A | KC633M | 5.5 | 6 | 14 | 21.6 | H | 0.1 | 2 | 26.75 € |
|
| 2CH0600ML028A | KC633M | 6 | 6 | 28 | 76 | H | 0.1 | 2 | 30.98 € |
|
| 2CH0600MR016A | KC633M | 6 | 6 | 23.8 | 50 | H | 0.1 | 2 | 26.75 € |
|
| 2CH0600MX038A | KC633M | 6 | 6 | 38 | 100 | H | 0.1 | 2 | 30.98 € |
|
| 2CH0700MR020A | KC633M | 7 | 7 | 20 | 63 | H | 0.1 | 2 | 36.90 € |
|
| 2CH0800ML028A | KC633M | 8 | 8 | 28 | 76 | H | 0.2 | 2 | 36.90 € |
|
| 2CH0800MR020A | KC633M | 8 | 8 | 20 | 63 | H | 0.2 | 2 | 25.78 € |
|
| 2CH0800MX041A | KC633M | 8 | 8 | 41 | 100 | H | 0.2 | 2 | 41.27 € |
|
| 2CH0900MR020A | KC633M | 9 | 9 | 20 | 63 | H | 0.2 | 2 | 51.03 € |
|
| 2CH1000ML032A | KC633M | 10 | 10 | 32 | 89 | H | 0.2 | 2 | 55.25 € |
|
| 2CH1000MR022A | KC633M | 10 | 10 | 22 | 72 | H | 0.2 | 2 | 51.03 € |
|
| 2CH1000MX045A | KC633M | 10 | 10 | 45 | 100 | H | 0.2 | 2 | 56.92 € |
|
| 2CH1100MR025A | KC633M | 11 | 11 | 25 | 76 | H | 0.3 | 2 | 61.65 € |
|
| 2CH1200ML045A | KC633M | 12 | 12 | 45 | 100 | H | 0.3 | 2 | 66.83 € |
|
| 2CH1200MR025A | KC633M | 12 | 12 | 25 | 76 | H | 0.3 | 2 | 59.19 € |
|
| 2CH1200MX075A | KC633M | 12 | 12 | 75 | 150 | H | 0.3 | 2 | 77.16 € |
|
| 2CH1400ML050A | KC633M | 14 | 14 | 50 | 100 | H | 0.3 | 2 | 80.08 € |
|
| 2CH1400MX075A | KC633M | 14 | 14 | 75 | 150 | H | 0.3 | 2 | 89.90 € |
|
| 2CH1600MR032A | KC633M | 16 | 16 | 32 | 89 | H | 0.3 | 2 | 95.00 € |
|
| 2CH1600MX075A | KC633M | 16 | 16 | 75 | 150 | H | 0.3 | 2 | 111.38 € |
|
| 2CH1800MX075A | KC633M | 18 | 18 | 75 | 150 | H | 0.3 | 2 | 145.6 € |
|
| 2CH2000ML056A | KC633M | 20 | 20 | 56 | 125 | H | 0.3 | 2 | 161.61 € |
|
| 2CH2000MX075A | KC633M | 20 | 20 | 75 | 150 | H | 0.3 | 2 | 167.44 € |
|
| 3CH0400DK005A | KC633M | 4 | 6 | 5 | 54 | H | 0.1 | 3 | 27.70 € |
|
| 3CH0400DL008A | KC633M | 4 | 6 | 15.8 | 57 | H | 0.1 | 3 | 27.70 € |
|
| 3CH0450DK005A | KC633M | 4.5 | 6 | 13.7 | 54 | H | 0.1 | 3 | 27.70 € |
|
| 3CH0450DL008A | KC633M | 4.5 | 6 | 6 | 57 | H | 0.1 | 3 | 27.70 € |
|
| 3CH0500DK006A | KC633M | 5 | 6 | 14.6 | 54 | H | 0.1 | 3 | 27.70 € |
|
| 3CH0500DL010A | KC633M | 5 | 6 | 10 | 57 | H | 0.1 | 3 | 27.70 € |
|
| 3CH0550DK007A | KC633M | 5.5 | 6 | 15.6 | 54 | H | 0.1 | 3 | 27.70 € |
|
| 3CH0550DL010A | KC633M | 5.5 | 6 | 18.6 | 57 | H | 0.1 | 3 | 27.70 € |
|
| 3CH0600DK007A | KC633M | 6 | 6 | 7 | 54 | H | 0.1 | 3 | 27.70 € |
|
| 3CH0600DL010A | KC633M | 6 | 6 | 10 | 57 | H | 0.1 | 3 | 27.70 € |
|
| 3CH0700DK008A | KC633M | 7 | 8 | 18.6 | 58 | H | 0.1 | 3 | 33.05 € |
|
| 3CH0700DL013A | KC633M | 7 | 8 | 23.6 | 63 | H | 0.1 | 3 | 35.78 € |
|
| 3CH0800DK009A | KC633M | 8 | 8 | 9 | 58 | H | 0.2 | 3 | 33.05 € |
|
| 3CH0800DL016A | KC633M | 8 | 8 | 16 | 63 | H | 0.2 | 3 | 35.78 € |
|
| 3CH1000DK011A | KC633M | 10 | 10 | 11 | 66 | H | 0.2 | 3 | 48.84 € |
|
| 3CH1000DL019A | KC633M | 10 | 10 | 19 | 72 | H | 0.2 | 3 | 51.03 € |
|
| 3CH1200DK012A | KC633M | 12 | 12 | 12 | 73 | H | 0.3 | 3 | 59.19 € |
|
| 3CH1200DL022A | KC633M | 12 | 12 | 22 | 83 | H | 0.3 | 3 | 61.65 € |
|
| 3CH1400DK014A | KC633M | 14 | 14 | 14 | 75 | H | 0.3 | 3 | 66.90 € |
|
| 3CH1400DL022A | KC633M | 14 | 14 | 22 | 83 | H | 0.3 | 3 | 76.80 € |
|
| 3CH1600DK016A | KC633M | 16 | 16 | 16 | 82 | H | 0.3 | 3 | 82.62 € |
|
| 3CH1600DL026A | KC633M | 16 | 16 | 26 | 92 | H | 0.3 | 3 | 96.00 € |
|
| 3CH1800DK018A | KC633M | 18 | 18 | 18 | 84 | H | 0.3 | 3 | 99.37 € |
|
| 3CH1800DL026A | KC633M | 18 | 18 | 26 | 92 | H | 0.3 | 3 | 112.47 € |
|
| 3CH2000DK020A | KC633M | 20 | 20 | 20 | 92 | H | 0.3 | 3 | 122.66 € |
|
| 3CH2000DL032A | KC633M | 20 | 20 | 32 | 104 | H | 0.3 | 3 | 140.50 € |
|
| 3CH0400MS012A | KC633M | 4 | 4 | 12 | 50 | H | 0.1 | 3 | 25.04 € |
|
| 3CH0400MX019A | KC633M | 4 | 4 | 19 | 63 | H | 0.1 | 3 | 25.04 € |
|
| 3CH0500MX020A | KC633M | 5 | 6 | 20 | 63 | H | 0.1 | 3 | 27.70 € |
|
| 3CH0600MS016A | KC633M | 6 | 6 | 16 | 50 | H | 0.1 | 3 | 26.75 € |
|
| 3CH0600MX028A | KC633M | 6 | 6 | 28 | 75 | H | 0.1 | 3 | 30.98 € |
|
| 3CH0800MS019A | KC633M | 8 | 8 | 19 | 63 | H | 0.2 | 3 | 35.78 € |
|
| 3CH0800MX028A | KC633M | 8 | 8 | 28 | 75 | H | 0.2 | 3 | 36.90 € |
|
| 3CH1000MS022A | KC633M | 10 | 10 | 22 | 76 | H | 0.2 | 3 | 51.03 € |
|
| 3CH1000MX032A | KC633M | 10 | 10 | 32 | 89 | H | 0.2 | 3 | 55.25 € |
|
| 3CH1200MS025A | KC633M | 12 | 12 | 25 | 75 | H | 0.3 | 3 | 59.19 € |
|
| 3CH1200MX045A | KC633M | 12 | 12 | 45 | 100 | H | 0.3 | 3 | 66.83 € |
|
| 3CH1600MS032A | KC633M | 16 | 16 | 32 | 89 | H | 0.3 | 3 | 95.00 € |
|
| 3CH1600MX056A | KC633M | 16 | 16 | 56 | 110 | H | 0.3 | 3 | 99.37 € |
|
| 3CH2000MX064A | KC633M | 20 | 20 | 64 | 125 | H | 0.3 | 3 | 161.61 € |
|
| 4CH0400DK008A | KC633M | 4 | 6 | 12.8 | 54 | H | 0.1 | 4 | 27.70 € |
|
| 4CH0400DL011A | KC633M | 4 | 6 | 15.77 | 57 | H | 0.1 | 4 | 27.70 € |
|
| 4CH0450DL011A | KC633M | 4.5 | 6 | 16.7 | 57 | H | 0.1 | 4 | 27.70 € |
|
| 4CH0500DK009A | KC633M | 5 | 6 | 14.634 | 54 | H | 0.1 | 4 | 27.70 € |
|
| 4CH0500DL013A | KC633M | 5 | 6 | 17.6 | 57 | H | 0.1 | 4 | 27.70 € |
|
| 4CH0550DL013A | KC633M | 5.5 | 6 | 18.6 | 57 | H | 0.1 | 4 | 27.70 € |
|
| 4CH0600DK010A | KC633M | 6 | 6 | 10 | 54 | H | 0.1 | 4 | 27.70 € |
|
| 4CH0600DL013A | KC633M | 6 | 6 | 13 | 57 | H | 0.1 | 4 | 27.70 € |
|
| 4CH0650DL016A | KC633M | 6.5 | 8 | 22.701 | 63 | H | 0.1 | 4 | 35.78 € |
|
| 4CH0700DK011A | KC633M | 7 | 8 | 18.6 | 58 | H | 0.1 | 4 | 33.05 € |
|
| 4CH0700DL016A | KC633M | 7 | 8 | 23.63 | 63 | H | 0.1 | 4 | 35.78 € |
|
| 4CH0800DK012A | KC633M | 8 | 8 | 12 | 58 | H | 0.2 | 4 | 33.05 € |
|
| 4CH0800DL019A | KC633M | 8 | 8 | 19 | 63 | H | 0.2 | 4 | 35.78 € |
|
| 4CH0900DK013A | KC633M | 9 | 10 | 22.6 | 66 | H | 0.2 | 4 | 48.84 € |
|
| 4CH0900DL019A | KC633M | 9 | 10 | 28.6 | 72 | H | 0.2 | 4 | 51.03 € |
|
| 4CH1000DK014A | KC633M | 10 | 10 | 14 | 66 | H | 0.2 | 4 | 48.84 € |
|
| 4CH1000DL022A | KC633M | 10 | 10 | 22 | 72 | H | 0.2 | 4 | 51.03 € |
|
| 4CH1200DK016A | KC633M | 12 | 12 | 16 | 73 | H | 0.3 | 4 | 59.19 € |
|
| 4CH1200DL026A | KC633M | 12 | 12 | 26 | 83 | H | 0.3 | 4 | 61.65 € |
|
| 4CH1400DK018A | KC633M | 14 | 14 | 18 | 75 | H | 0.3 | 4 | 66.90 € |
|
| 4CH1400DL026A | KC633M | 14 | 14 | 26 | 83 | H | 0.3 | 4 | 76.80 € |
|
| 4CH1600DK022A | KC633M | 16 | 16 | 22 | 82 | H | 0.3 | 4 | 82.62 € |
|
| 4CH1600DL032A | KC633M | 16 | 16 | 32 | 92 | H | 0.3 | 4 | 95.00 € |
|
| 4CH1800DK024A | KC633M | 18 | 18 | 24 | 84 | H | 0.3 | 4 | 99.37 € |
|
| 4CH1800DL032A | KC633M | 18 | 18 | 32 | 92 | H | 0.3 | 4 | 112.47 € |
|
| 4CH2000DK026A | KC633M | 20 | 20 | 26 | 92 | H | 0.3 | 4 | 122.66 € |
|
| 4CH2000DL038A | KC633M | 20 | 20 | 38 | 104 | H | 0.3 | 4 | 140.50 € |
|
| 4CH0400ML019A | KC633M | 4 | 4 | 19 | 63 | H | 0.1 | 4 | 25.04 € |
|
| 4CH0400MR011A | KC633M | 4 | 4 | 11 | 50 | H | 0.1 | 4 | 25.04 € |
|
| 4CH0400MX031A | KC633M | 4 | 4 | 31 | 75 | H | 0.1 | 4 | 28.28 € |
|
| 4CH0500MR030A | KC633M | 5 | 5 | 30 | 75 | H | 0.1 | 4 | 27.84 € |
|
| 4CH0600ML028A | KC633M | 6 | 6 | 28 | 75 | H | 0.1 | 4 | 30.98 € |
|
| 4CH0600MR016A | KC633M | 6 | 6 | 22.1 | 50 | H | 0.1 | 4 | 26.75 € |
|
| 4CH0600MX038A | KC633M | 6 | 6 | 38 | 100 | H | 0.1 | 4 | 30.98 € |
|
| 4CH0800ML028A | KC633M | 8 | 8 | 28 | 75 | H | 0.2 | 4 | 36.90 € |
|
| 4CH0800MR020A | KC633M | 8 | 8 | 25.44 | 50 | H | 0.2 | 4 | 31.59 € |
|
| 4CH0800MX041A | KC633M | 8 | 8 | 41 | 100 | H | 0.2 | 4 | 41.27 € |
|
| 4CH1000ML032A | KC633M | 10 | 10 | 32 | 89 | H | 0.2 | 4 | 55.25 € |
|
| 4CH1000MR022A | KC633M | 10 | 10 | 22 | 72 | H | 0.2 | 4 | 51.03 € |
|
| 4CH1000MX045A | KC633M | 10 | 10 | 45 | 100 | H | 0.2 | 4 | 56.92 € |
|
| 4CH1200ML045A | KC633M | 12 | 12 | 45 | 100 | H | 0.3 | 4 | 66.83 € |
|
| 4CH1200MR025A | KC633M | 12 | 12 | 25 | 89 | H | 0.3 | 4 | 61.65 € |
|
| 4CH1200MX075A | KC633M | 12 | 12 | 75 | 150 | H | 0.3 | 4 | 77.16 € |
|
| 4CH1400ML050A | KC633M | 14 | 14 | 50 | 100 | H | 0.3 | 4 | 80.08 € |
|
| 4CH1400MR032A | KC633M | 14 | 14 | 32 | 83 | H | 0.3 | 4 | 76.80 € |
|
| 4CH1400MX075A | KC633M | 14 | 14 | 75 | 150 | H | 0.3 | 4 | 89.90 € |
|
| 4CH1600ML056A | KC633M | 16 | 16 | 56 | 110 | H | 0.3 | 4 | 99.37 € |
|
| 4CH1600MR032A | KC633M | 16 | 16 | 32 | 92 | H | 0.3 | 4 | 95.00 € |
|
| 4CH1600MX075A | KC633M | 16 | 16 | 75 | 150 | H | 0.3 | 4 | 111.38 € |
|
| 4CH1800ML060A | KC633M | 18 | 18 | 60 | 125 | H | 0.3 | 4 | 134.68 € |
|
| 4CH1800MR038A | KC633M | 18 | 18 | 38 | 100 | H | 0.3 | 4 | 128.85 € |
|
| 4CH1800MX075A | KC633M | 18 | 18 | 75 | 150 | H | 0.3 | 4 | 145.6 € |
|
| 4CH2000ML056A | KC633M | 20 | 20 | 56 | 125 | H | 0.3 | 4 | 161.61 € |
|
| 4CH2000MR038A | KC633M | 20 | 20 | 38 | 104 | H | 0.3 | 4 | 140.50 € |
|
| 4CH2000MX075A | KC633M | 20 | 20 | 75 | 150 | H | 0.3 | 4 | 167.44 € |
|
